Product details
This assembled GTV-2 head pairs 90.5/92mm cylinders with single high-rev valve springs. The Manley stainless valves measure 40mm intake and 35.5mm exhaust, with chromoly retainers and hardened keepers. It is the single-spring version of this head, so the spring setup can be chosen to suit the engine's valve train.
Technical Details
- Part number: 98-1333-B
- Bore: 90.5/92mm
- Valves: 40 x 35.5mm
- Springs: Single
- Chamber: 56cc
- Plug specification: 12mm thread, 3/4-inch reach
- Included: Rocker, intake and exhaust studs; three-angle valve work
- Quantity: Each
Fitment & Compatibility
For Type 1-style dual-port engines with 90.5/92mm cylinders. Establish chamber volume, deck clearance, and cam and rocker compatibility before assembly. EMPI requires lash caps 00-4006-0 with its stainless-valve applications. Check the spark plugs and all valve-train clearances before operation.
