CSF Front Fender Oil Cooler for Porsche 964 / 993

Replace the supported 964/993 front oil cooler with a CSF dual-pass aluminum unit. Match the original cooler reference and M30 hose connections; this is the fender cooling assembly, separate from earlier engine-mounted coolers.

Technical Details

• Fabspeed catalog reference: 8334.
• CSF reference 8334.
• Dual-pass 50 mm tube-and-fin core.
• Stainless M30 × 1.5 high-flow fittings.
• Revised fan-shroud mounting locations.
• TIG-welded all-aluminum construction with satin-black finish.
• Original cooler references 96420722002, 96420722003 and 96420722004.
• Individually pressure tested at 8 bar / 116 psi.
• Ten-year limited CSF warranty, subject to terms.
• Use supplied torque specifications and confirm hoses/fan mounting.

Product Videos

Demonstration cars may have additional modifications. The selected configuration determines what is supplied; a video does not establish another vehicle’s fitment or guarantee identical sound or output.

With over 20 years of parts experience, PMB Performance can help check the application. Share your VIN and photos or references for the component being replaced before ordering if the match is uncertain.

Fitment & Compatibility

Use the application details below together with the original component and any existing modifications.
