Product details
The EMPI 17-2733-0 Undrilled Billet Bracket is a two-piece billet aluminum clamp for 1 1/2 inch tubing with a blank mounting face, so you drill the holes to suit the accessory you are attaching. The clamp halves are held with through-bolts, and the bracket is 3 1/2 inches wide. A blank face helps when an accessory has an odd hole pattern or needs to sit in a specific spot. Builders use these on cages and roll bars for gauges, switches, and lights. It is sold individually.
The two undrilled sizes differ in more than tube diameter. This 1 1/2 inch version uses the through-bolt design, while the 1 3/4 inch version (17-2734) has threaded bolts and is 3 3/4 inches wide. To skip drilling, EMPI also makes pre-drilled brackets for 1 1/2 inch tube, including the 17-2732 Narrow bracket (2 1/8 inches wide, 1/4-20 threads) and the 17-2737 Side Drilled bracket (3 1/2 inches wide).
Technical Details
- Manufacturer: EMPI
- Manufacturer part number: 17-2733-0
- Material: billet aluminum, polished
- Tube size: 1 1/2 inch
- Width: 3 1/2 inches
- Design: two-piece through-bolt clamp, undrilled face
- Sold as: Each
Fitment & Compatibility
Universal fit for 1 1/2 inch outside diameter tubing on sand rails, buggies, Baja Bugs, and other off-road cars. For 1 3/4 inch tube, order 17-2734.
Installation & Tuning Notes
Drill the face with the bracket off the car. Lay out holes to clear the clamp bolts and the tube bore, center punch each one, and start with a small pilot drill before stepping up to final size.
Common Questions
What does "undrilled" mean here?
The mounting face has no accessory holes, so you drill them exactly where you need them.
Is there a 1 3/4 inch version?
Yes, 17-2734. It uses threaded bolts and is 3 3/4 inches wide.
